Electric Forklift
PRODUCT SERIES: Electric Forklift
Color:
-
Product Features
1. Green and environmental friendly
Lower carbon,cleaner,low noise,no dirty tail gas,no acid mist.
2. Easy to maintain
The engin hood can be opened at a large angle to facilitate maintenance and battery replacement.
3. Low maintenance cost
Lithium battery is maintenance-free,with less maintenance cost.
Product Application Scope
Electric forklifts are applicable to logistics, handling, stacking, loading and unloading in the industrial production field, and can be widely used in storage, logistics, manufacturing, processing and other fields.
Product Parameters
Program
unit
CPD35E
Type of power
Lithium battery
Rated capacity
kg
3500
Load center
mm
500
Lifting height
mm
3000
Free lifting height
mm
120
Fork size
mm
50*125*1070
Mast tilt angle
°
Front 6 rear 10
Overall dimension
Overall length (excluding fork)
mm
2870
Overall Width
mm
1230
Height of mast not lifting
mm
2070
Height of overhead guard
mm
2190
Min.Turning radius
mm
2645
Max.Travel speed(full-load/unload)
Km/h
11\12
Max.Lifting speed(full-load)
m/s
0.26
Max.Gradeability
%
15
Total weight
kg
4650
Tire
Front wheel
28×9-15-14PR
Rear wheel
6.50-10-10PR
wheel track
Front wheel
mm
1010
Rear wheel
mm
980
Wheelbase
mm
1810
electric motor
electric motor
Drive motor rated power S2 60 minutes
kW
10
Rated power of lifting motor S3 15%
kw
12
Battery voltage/nominal capacity
V/Ah
80/280
Type of drive unit
alternating current (AC)
Products Detail Picture
